Remove the fuel rail

WARNING: This page is about a different variant/trim than selected.
Fig 1: Identifying Holder
GLL125822Courtesy of VOLVO CARS OF NORTH AMERICA.

Install holder 9995533 (5x) on the injectors

Disconnect fuel pressure regulator vacuum hose.

Lift up and put fuel rail with injectors to one side.

CAUTION: Take care not to damage the injector nozzles and fuel needles.
