Removing the oil pipe from the transmission

WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying O-Ring
GLL109367Courtesy of VOLVO CARS OF NORTH AMERICA.

Collect the, approximately, 1/2 - 1 dl of oil that runs out when the oil pipe is detached from the transmission.

Slacken off the screw. Pull the pipe out of the transmission.

Plug the oil pipe and the transmission.
