Removing the Drive Shaft From the Transmission, Continued

WARNING: This page is about a different car, the 2002 Volvo C70, 2001 Volvo C70, 2000 Volvo C70, 1999 Volvo C70, and 1998 Volvo C70. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Removing Drive Shaft From Transmission Using 999 5462
GLL126279Courtesy of VOLVO CARS OF NORTH AMERICA.
NOTE: Applies only to vehicles with M66AWD transmissions and drive shafts with a tripod joint.

Position the two tools opposite each other. Detach the drive shaft.

NOTE: Cars with Cross-grove drive shaft joints and M66AWD transmissions. Use jimmy bar 9995462 B as above.

Remove the drive shaft from the transmission. Ensure that the end of the drive shaft does not damage the seal.
