Power Unit: Removal

Fig 1: Blower Fan Motor With Fan Hub

GLL105174

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove:

the blower fan motor with the fan hub as above, see Fan Motor

Remove:

the power unit, 2 screws.
