Installing the heated oxygen sensor (HO2S) connectors to the bracket on the transmission

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2006 Volvo S80, 2005 Volvo S80, 2004 Volvo S80, 2003 Volvo S80, and 2002 Volvo S80. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Heated Oxygen Sensor

Courtesy of VOLVO CARS OF NORTH AMERICA.

Connect the connectors.

Secure the connectors on the bracket.

Install the clamp with the wiring on the transmission. Tighten the nut.

Lower the vehicle.
