Parking Aid Bracket, Removing And Installing, In Air Grille: Removing
WARNING: This page is about a different car, the 2023 Volkswagen Arteon. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the bumper. Refer to BUMPER COVER, REMOVING AND INSTALLING .
-- Disconnect the connector, and remove the sensor if necessary. Refer to OVERVIEW - PARKING AID / PARALLEL PARKING ASSIST / AUTONOMOUS PARKING .
-- Remove the bolts -8-.
-- Remove the bracket -4- from the upper retainers.
Installing
-- Engage the bracket -4- in the upper retainers.
-- Tighten the bolts -8-.
-- The brackets are bolted in the air grille.
-- Align the connections of both sensors are aligned outward -arrows-.
Tightening Specifications
- Refer to OVERVIEW - RADIATOR GRILLE
