Overview - Lock Carrier, Sedan
WARNING: This page is about a different variant/trim than selected.
- Lock Carrier with Attachments
- Removing and Installing. Refer to LOCK CARRIER, REMOVING AND INSTALLING .
- Service position. Refer to SERVICE POSITION, IMPLEMENTING AND RESETTING .
- Air Duct
- Bolt
- 2 Nm
- Quantity: 2
- Bolt
- 8 Nm
- Quantity: 3 on each side
- Retaining Bracket
- Left
- Air Duct
- Left
- Bolt
- 8 Nm
- Quantity: 2 on each side
- For attaching the bumper carrier -9- to the lock carrier -1-
- Bolt
- 60 Nm
- Quantity: 4 on each side
- Bumper Carrier
- Overview. Refer to OVERVIEW - IMPACT MEMBER .
- Air Duct
- Right
- Retaining Bracket
- Right
