Removal [08/2015 - 08/2019]: Procedure

  1. REMOVE NO. 1 INSTRUMENT CLUSTER FINISH PANEL GARNISH

    Refer to PROCEDURE - Step 1

  2. REMOVE NO. 2 INSTRUMENT CLUSTER FINISH PANEL GARNISH

    Refer to PROCEDURE - Step 2

  3. REMOVE HEATER CONTROL ASSEMBLY

    Refer to PROCEDURE - Step 3

  4. REMOVE RADIO AND DISPLAY RECEIVER ASSEMBLY WITH BRACKETS
    1. Remove the 4 bolts.
      GTY343584Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Pull the radio and display receiver assembly with brackets as shown in the illustration to detach the 6 claws on the backside of the radio and display receiver assembly with brackets.
      GTY687456Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    3. Disconnect each connector to remove the radio and display receiver assembly with brackets.
      GTY445992Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  5. REMOVE HAZARD SWITCH WIRE
    1. Detach the 2 clamps.
      GTY445988Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    2. Disconnect the connector to remove the hazard switch wire.
  6. REMOVE NO. 1 RADIO BRACKET
    1. Remove the 3 screws and No. 1 radio bracket.
      GTY445989Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  7. REMOVE NO. 2 RADIO BRACKET
    1. Remove the 3 screws and No. 2 radio bracket.
      GTY445987Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
