Compressor And Magnetic Clutch: Installation

WARNING: This page is about a different car, the 2007 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.

INSTALL COOLER COMPRESSOR ASSEMBLY
1. Install the compressor with the 3 bolts.
  Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf)
2. Connect the connector.
INSTALL FRONT DRIVE SHAFT LH
1. Install the drive shaft (see INSTALLATION ).
CONNECT DISCHARGE AND SUCTION HOSES
1. Sufficiently apply compressor oil to a new O-rings and the fitting surface of the hoses.
  Compressor oil: ND-OIL 8 or equivalent

  Fig 1: Installing Front Drive Shaft LH
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Connect the both suction hoses with the 2 bolts.
  NOTE: Hose should be connected immediately after the caps have been removed.
INSTALL DRIVE BELT (See INSTALLATION )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION
1. Perform initialization (see INITIALIZATION ).
  NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

  Fig 2: Connecting Both Suction Hoses With Bolts
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
CHARGE REFRIGERANT (See REPLACEMENT )
WARM UP ENGINE (See REPLACEMENT )
CHECK FOR LEAKAGE OF REFRIGERANT (See REPLACEMENT )
