Instrument Cluster Removal

  1. Remove the instrument cluster trim panel. Refer to Instrument Cluster Trim Panel Removal  .
  2. Remove the screws and the instrument cluster.
Fig 1: Removing Instrument Cluster
G02996837Courtesy of SUZUKI OF AMERICA CORP.
