Transfer Clutch: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Remove the transmission assembly from the vehicle. Ref. to CONTINUOUSLY VARIABLE TRANSMISSION (TR580)>Automatic Transmission Assembly>REMOVAL .
  2. Remove the extension case. Ref. to CONTINUOUSLY VARIABLE TRANSMISSION (TR580)>Extension Case>REMOVAL .
  3. Remove the transfer clutch assembly.
    Fig 1: Removing Transfer Clutch Assembly
    G08317898Courtesy of SUBARU OF AMERICA, INC.
  4. Remove the thrust bearing.
    Fig 2: Removing Thrust Bearing
    G08317899Courtesy of SUBARU OF AMERICA, INC.
  5. Remove the seal ring from transfer clutch assembly.
    Fig 3: Locating Seal Ring From Transfer Clutch Assembly
    G08317900Courtesy of SUBARU OF AMERICA, INC.
  6. Remove the seal ring from the transfer driven gear assembly.
Fig 4: Locating Seal Ring From Transfer Driven Gear Assembly
G08317901Courtesy of SUBARU OF AMERICA, INC.
