Engine Coolant Temperature Sensor: Removal

WARNING: This page is about a different variant/trim than selected.

Disconnect the ground terminal from battery sensor. Ref. to NOTE>NOTE>BATTERY .
Drain engine coolant. Ref. to COOLING(H4DO)>Engine Coolant>REPLACEMENT>DRAINING OF ENGINE COOLANT .
Disconnect the connector (A) from the engine coolant temperature sensor, and remove the engine coolant temperature sensor.

Fig 1: Locating Engine Coolant Temperature Sensor

Courtesy of SUBARU OF AMERICA, INC.
