DTC 12 Compare Error In Other Sensor
DTC detecting condition:
Error in comparison with other brake booster relative pressure
Trouble symptom:
Brake vacuum pump does not operate.
CAUTION:
Use the check board when measuring the ECM terminal voltage and resistance.
Wiring diagram:
Vacuum pump control system Ref. to WIRING SYSTEM>Vacuum Pump Control System>WIRING DIAGRAM .
