Steering Angle Sensor Malfunction
DTC C0071 STEERING ANGLE SENSOR MALFUNCTIONDTC DETECTING CONDITION:
Defective steering angle sensor
TROUBLE SYMPTOM:
^ ABS does not operate.
^ VDC does not operate.
NOTE:
^ Warning light does not illuminate though problem is detected.
^ The ABS and VDC operate normally if voltage returns.
WIRING DIAGRAM:
