C0047
DTC C0047 CAN COMMUNICATIONDTC DETECTING CONDITION:
CAN communication line circuit is open or shorted.
TROUBLE SYMPTOM:
^ ABS does not operate.
^ VDC does not operate.
WIRING DIAGRAM:
DTC DETECTING CONDITION:
CAN communication line circuit is open or shorted.
TROUBLE SYMPTOM:
^ ABS does not operate.
^ VDC does not operate.
WIRING DIAGRAM:
