C0042

DTC C0042 POWER SUPPLY VOLTAGE FAILURE

DTC DETECTING CONDITION:
Improper VDCCM&H/U power supply voltage

TROUBLE SYMPTOM:
^ ABS does not operate.
^ EBD may not operate.
^ VDC does not operate.

NOTE:
Warning lights go off if voltage returns.

WIRING DIAGRAM:
