Exhaust Side

WARNING: This page is about a different variant/trim than selected.

Disconnect the ground cable from battery.

Fig 1: Identifying Ground Cable And Battery
Courtesy of SUBARU OF AMERICA, INC.
Lift up the vehicle.
Remove the under cover. Ref. to REMOVAL , Front Under Cover.
Disconnect the connector from the camshaft position sensor, and remove the camshaft position sensor.
- RH side

  Fig 2: Locating Camshaft Position Sensor Connector And Bolt (RH Side)
  Courtesy of SUBARU OF AMERICA, INC.
- LH side

  Fig 3: Locating Camshaft Position Sensor Connector And Bolt (LH Side)
  Courtesy of SUBARU OF AMERICA, INC.
