Air Breather Hose: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Remove the air intake boot assembly. Ref. to REMOVAL , Air Intake Boot.
  2. Remove the two air breather hoses.
    Fig 1: Identifying Air Breather Hoses
    G06654490Courtesy of SUBARU OF AMERICA, INC.
  3. Remove the oil cap.
Fig 2: Identifying Oil Cap
G06654491Courtesy of SUBARU OF AMERICA, INC.
