Release Bearing and Lever: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Remove the transmission assembly from vehicle body.

    < Ref. to REMOVAL , Manual Transmission Assembly. >

  2. Remove the two clips from clutch release lever and remove the release bearing.
    CAUTION: Be careful not to deform the clips.
  3. Remove the dust cover.
    Fig 1: Removing Two Clips From Clutch
    G03832212Courtesy of SUBARU OF AMERICA, INC.
  4. Remove the lever spring from pivot with a screwdriver by accessing it through the clutch housing release lever hole. Then remove the release lever.
    Fig 2: Removing Lever Spring From Pivot With A Screwdriver
    G03832213Courtesy of SUBARU OF AMERICA, INC.
