Checking the door window highest position

WARNING: This page is about a different car, the 2011 Saab 9-3 and 2010 Saab 9-3. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise the soft top fully.
  2. Shut the windows.
  3. The edge of the door window must run precisely and freely against the lip of the seal when the door is closed (A  ). The window must then lightly touch the lip of the seal if it correctly adjusted for height. When the door is closed the lip of the seal must close around the edge (B  ).
    Fig 1: Identifying Windows And Door Mirror Base Seal Position
    G05063256Courtesy of SAAB-SCANIA OF AMERICA, INC.
