Removing Sealing Ring For CARDAN Flange

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Sealing ring and circlip

1. 2.1  Pierce two holes in the dust boot using a mandrel.
2. 2.2  Screw in tapping screws -arrows-  with a diameter of 4 mm.
3. 2.3  Pull out dust boot using > T10055 - puller. > Tapping screws in dust boot

Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Tapping screws in dust boot

1. 3.1  Pierce two holes in the sealing ring using a mandrel.
2. 3.2  Screw in tapping screws with a diameter of 4 mm.
3. 3.3  Pull out sealing ring using > T10055 - puller.
