Camshaft allocation
WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2005 Porsche 911, 2004 Porsche 911, 2003 Porsche 911, 2002 Porsche 911, and 2001 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
Camshafts of cylinder bank 1 - 3
IDENTIFICATION ON THE INLET CAMSHAFT (CYLINDER BANK 1 - 3)
| Inlet camshaft: | 221.55/3.4 IN 13 |
IDENTIFICATION ON THE EXHAUST CAMSHAFT (CYLINDER BANK 1 - 3)
| Exhaust camshaft: | 222.55/3.4 EX 13 |
Camshafts of cylinder bank 4 - 6
IDENTIFICATION ON THE CAMSHAFTS (CYLINDER BANK 4 - 6)
| Inlet camshaft: | 216.55/3.4 IN 46 |
| Exhaust camshaft: | 218.55/3.4 EX 46 |
