Installing Backrest Side Support
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
Information
Observe hose routing!
In vehicles with lumbar support, make sure the hoses are routed correctly in the area of the backrest side support.
- Fit backrest side support -2- and screw down with the four fastening screws -1- .
