Preliminary Work

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise the vehicle → 400000 LIFTING THE VEHICLE .
  2. Remove front underbody panel → 519219 REMOVING AND INSTALLING FRONT COVER .
  3. Remove underbody panels in the center (left side) → 519319 REMOVING AND INSTALLING CENTRE UNDERBODY COVER .
    Fig 1: Lateral View Of Cover (Above Pressure And Return Lines)
    G09826394Courtesy of PORSCHE CARS NORTH AMERICA, INC.
