Removing and installing blower driver: Removal

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2005 Porsche 911, 2004 Porsche 911, 2003 Porsche 911, 2002 Porsche 911, and 2001 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove footwell bulkhead and right air guide. Unscrew fastening screw and detach the blower driver from the heating/air-conditioning unit housing from below.
    Fig 1: Removing Footwell Bulkhead And Right Air Guide And Fastening Screw
    G03092959Courtesy of PORSCHE OF NORTH AMERICA, INC.
  2. Pull blower driver out of the upper bracket and remove in downward direction.
  3. Pull off electrical plug connection.
