Engine Number Marking - Panamera Diesel

WARNING: This page is about a different variant/trim than selected.
G15197620Courtesy of PORSCHE CARS NORTH AMERICA, INC.

Engine number

The engine number ("Engine code" and "Serial number") can be found at the front left, underneath the toothed belt for the high-pressure pump -arrow-  . In addition, a sticker showing "Engine code" and "Serial number" is affixed to the intake pipe.
