Rear Window Washer Nozzle Replacement

WARNING: This page is about a different car, the 2009 Pontiac Torrent and 2009 Chevrolet Equinox. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: View Of Rear Window Washer Nozzle
GM1716309Courtesy of GENERAL MOTORS CORP.
Callout Component Name
Preliminary Procedure:
Remove the rear spoiler. Refer to Rear Spoiler Replacement .
1 Center High Mounted Stop Lamp Screw (Qty: 2)
CAUTION: Refer to Fastener Caution .

Tighten:  2.5 N.m (22 lb in)
2 Center High Mounted Stop Lamp Assembly

Procedure

  1. Disconnect the rear washer hose from the rear washer nozzle.
  2. Remove the rear washer nozzle from the stop lamp assembly if replacing.
  3. Disconnect the electrical connector.
3 Rear Windshield Washer Nozzle
Procedure:
Rotate the rear washer nozzle 45 degrees counterclockwise and remove the nozzle.
