Removal and Installation: Notes
WARNING: This page is about a different car, the 2018 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
|
1.
|
Air duct hose and resonator assembly
|
2.
|
Front air duct
|
3.
|
Air cleaner case (lower)
|
|
4.
|
Grommets
|
5.
|
Air cleaner case mounting bracket
|
6.
|
Bracket
|
|
7.
|
Air cleaner filter
|
8.
|
Air cleaner case (upper)
|
9.
|
Mass air flow sensor
|
|
A.
|
To electric throttle control actuator
|
B.
|
Air cleaner case side clips
|
