Oil Level

WARNING: This page is about a different car, the 2018 Nissan Titan XD. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove filler plug (1) and check oil level (A) from filler plug hole as shown.
    GNSAWDIA1368Z-368Courtesy of NISSAN NORTH AMERICA, INC.
    CAUTION: Do not start engine while checking oil level.
  2. Install filler plug and tighten to specification.

    Filler plug torque

    : Refer to Exploded View .
