Combination Meter

  1. Remove cluster lid A. Refer to, "CLUSTER LID A ".
  2. Remove screws using power tool.
    • Pull cluster lid A from opening.
    • Disconnect electrical connectors.
    • Remove combination meter.
  3. Installation is in the reverse order of removal.
    Fig 1: Removing Combination Meter
    G02888380Courtesy of NISSAN MOTOR CO., U.S.A.
