Removal And Installation: Notes

WARNING: This page is about a different variant/trim than selected.
Fig 1: Oil Pan And Timing Chain Case Components With Torque Specifications
G09619813Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

Required Special Tool:
