LOGIC FLOW CHARTS (Monitor Sequence) < Functional check - Shift fork 1 requested but shift fork 3 movement >

WARNING: This page is about a different variant/trim than selected.
Fig 1: Monitor Sequence Logic Flow Charts (Functional Check - Neutral)
G09625836Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
