Removal And Installation: Notes

WARNING: This page is about a different car, the 2008 Mitsubishi Lancer. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Compressor Assembly And Tension Pulley Replacement Components With Torque Specifications
G05397406Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
