WARNING: This page is about a different car, the 2008 Mitsubishi Lancer. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Connecting Compressor Connector Terminal To Battery
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Fig 2: Exploded View Of Compressor Assembly And Tension Pulley With Torque Specifications
