61 62 060 Removing and installing/replacing rear wiper motor

WARNING: This page is about a different car, the 2019 MINI Cooper, 2018 MINI Cooper, 2017 MINI Cooper, 2016 MINI Cooper, and 2015 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Preliminary work needed:

Remove WIPER ARM FOR REAR WIPER
Remove TRIM FOR TRUNK LID AT BOTTOM

Removal:

Unlock hose pipe (1) and disconnect.

Unlock and disconnect connector (2).

Loosen screws.

Pull wiper motor (3) out of grommet (4).

Fig 1: Pulling Wiper Motor Out Of Grommet

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

NOTE: Check grommet (4) of wiper pivot for signs of damage, replace if necessary.

Join wiper motor (3) in grommet (4).

Tighten down screws (3).

Tightening torque 61 62 2AZ .

Connect connector (2).

Connect hose pipe (1).

Fig 2: Pulling Wiper Motor Out Of Grommet

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Ensure fit and detent of hose pipe (1) are correct.

Required follow-up work:

Adjust SPRAY NOZZLE .
