63 31 080 Removing and installing/replacing trunk compartment light (Cooper Convertible)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2021 MINI Cooper, 2020 MINI Cooper, 2019 MINI Cooper, 2018 MINI Cooper, and 2017 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

64 1 020

IMPORTANT: Follow instructions for handling LIGHT BULBS (INTERIOR LIGHTS) .

Removal:

Lever out the trunk compartment light (1) using special tool 64 1 020.

Disconnect associated plug and remove trunk compartment light (1).

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

If necessary, remount BULB , check BULB TYPE .

Installation:

Connect associated plug and join trunk compartment light (1).

NOTE: Make sure the trunk compartment light (1) is positioned correctly.

Courtesy of BMW OF NORTH AMERICA, INC.
