63 99 230 Replacing halogen bulb for left or right fog lamp (M aerodynamics package)

WARNING: This page is about a different car, the 2003 BMW 530i, 2002 BMW 530i, and 2001 BMW 530i. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Follow instructions for handling light bulbs (exterior lights). Refer to 63 99... INSTRUCTIONS FOR HANDLING LIGHT BULBS (EXTERIOR LIGHTS) .

Remove fog lamp, refer to 63 17 000 REMOVING AND INSTALLING/REPLACING LEFT OR RIGHT FOG LAMP INSERT (COMPLETE) .

Turn bulb with holder (1) in direction of arrow and remove.

Installation:

Note type of bulb, refer to LIGHTS - TECHNICAL DATA .

Fig 1: Removing Fog Lamp Bulb With Holder (M Aerodynamics Package)

Courtesy of BMW OF NORTH AMERICA, INC.
