11 21 500 Removing and installing/replacing crankshaft (W10)

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2008 MINI Cooper, 2007 MINI Cooper, 2006 MINI Cooper, 2005 MINI Cooper, and 2004 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Necessary Preliminary Tasks:

Remove engine. Refer to 11 00 050 REMOVING AND INSTALLING ENGINE .
Remove cylinder head. Refer to 11 12 100 REMOVING AND INSTALLING/SEALING CYLINDER HEAD W10 .
Remove flywheel. Refer to 11 22 500 REMOVING AND INSTALLING OR REPLACING FLYWHEEL .
Remove crankshaft main bearings. Refer to 11 21 531 REPLACING CRANKSHAFT MAIN BEARING SHELLS W10 .

CAUTION: CAREFULLY place crankcase to one side (risk of breakage).

Release screws (1).

Fit incremental wheel (2) on new crankshaft.

Tightening torque: 11 21 1AZ in ENGINE - TIGHTENING TORQUES- COOPER (1.6L) R50/W10 .

Fig 1: Fitting Incremental Wheel On Crankshaft

Courtesy of BMW OF NORTH AMERICA, INC.

Assemble engine.

Installation Note:

Lubricate all bearing points with engine oil.
