51 11 701 Replacing bracket for bumper, front left or right (Z3 Roadster, M Roadster, Z3 Coupe, M Coupe)

WARNING: This page is about a different car, the 2002 BMW Z3 and 2001 BMW Z3. However, it is still accessible from the selected car via links, so may be relevant.

(Bumper Removed)

(If necessary, remove front bumper, refer to 51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (Z3 ROADSTER, M ROADSTER) .)

Installation:

If necessary, mark position of bracket on body.

Unfasten nut (1) from wheel arch and remove bracket (2).

Fig 1: Adjusting Front Bumper

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Adjust front bumper, refer to 51 11 000 REMOVING AND INSTALLING COMPLETE FRONT BUMPER (Z3 ROADSTER, M ROADSTER) .
