35 11 000 Removing and installing (replacing) complete bearing support for foot pedal

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2017 BMW M6, 2017 BMW 650i xDrive, 2017 BMW 650i, 2017 BMW 640i xDrive, and 2017 BMW 640i. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: After completion of work, perform a functional check.

Necessary preliminary tasks:

Remove BRAKE BOOSTER

Release screws (1).

Remove control units from holder (2). Plugs remain connected.

Fig 1: Identifying Holder And Screws

G10045959

Courtesy of BMW OF NORTH AMERICA, INC.

Slacken nut (1).

Installation note:

Replace self-locking nut.

Tightening torque 35 11 2AZ .

Remove bearing block (2).

Fig 2: Identifying Bearing Block And Nut

G06894911

Courtesy of BMW OF NORTH AMERICA, INC.

Unclip line (1).

Disconnect plug connection (2).

Replacement:

Modify BRAKE LIGHT SWITCH
Modify holder for control units
Modify clutch pedal

Fig 3: Identifying Plug Connection And Line

Courtesy of BMW OF NORTH AMERICA, INC.
