67 31 540 Removing and installing/replacing backrest upper section adjustment motor

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2017 BMW M6, 2017 BMW 650i xDrive, 2017 BMW 650i, 2017 BMW 640i xDrive, and 2017 BMW 640i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove the backrest cover from the front seat. See DRIVER'S SEAT BACKREST COVER (NORMAL/ELECTRIC) , FRONT PASSENGER SEAT BACKREST COVER (NORMAL/ELECTRIC) , DRIVER'S SEAT BACKREST COVER (SPORT) , or FRONT PASSENGER SEAT BACKREST COVER (SPORT) .

Unfasten plug connection (1) and disconnect.

Unfasten screws (2).

Tightening torque 67 31 4AZ .

Remove the powertrain (3) from the gearbox.

Fig 1: Removing Powertrain From Gearbox

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE:

Carry out FUNCTION CHECK WITH ADAPTER CABLE
INITIALIZE the drive for backrest upper section adjustment
