52 17 034 Removing and installing/replacing shaft for head restraint adjustment

WARNING: This page is about a different car, the 2011 BMW X6 and 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove FRONT SEAT
Remove BOTH REAR PANELS
Remove INNER COVER

Bend shaft (1) in direction of arrow.

Pull shaft (1) out of gear (2) and remove.

Fig 1: Removing Shaft From Gear

Courtesy of BMW OF NORTH AMERICA, INC.
