64 11 225 Replacing controller for heating and A/C system blower

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2016 BMW 760Li, 2015 BMW 760Li, 2014 BMW 760Li, 2013 BMW 760Li, and 2012 BMW 760Li. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove BLOWER HOUSING FOR HEATING AND AIR-CONDITIONING UNIT

Unlock plug connections (1) and disconnect.

Release screws (3).

Remove controller (2) towards top.

Fig 1: Identifying Roof Shell Screw

Courtesy of BMW OF NORTH AMERICA, INC.
