12 31 020 Removing and installing/replacing alternator (M62): Installation:

WARNING: This page is about a different car, the 2003 BMW X5, 2002 BMW X5, 2001 BMW X5, and 2000 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

Replace sealing ring (1) on alternator.

Fig 1: Pulling Out Alternator
G03252216Courtesy of BMW OF NORTH AMERICA, INC.
NOTE: If necessary, replace alternator belt pulley, refer to 12 31 ... REPLACING ALTERNATOR BELT PULLEY
Top up coolant, refer to 17 00 005 .
Vent cooling system and check for leaks, refer to 17 00 039 .
