51 71 039 Removing and installing/replacing front left or right wheel arch cover (rear section)

WARNING: This page is about a different car, the 2010 BMW M3, 2009 BMW M3, and 2008 BMW M3. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

If necessary, remove front wheel

NOTE: In event of further work, where possible, leave wheel arch cover on vehicle.
Wheel arch cover must not be cut.
In case of complete removal or replacement, release spring strut . See 33 53 000 REMOVING AND INSTALLING / REPLACING REAR LEFT OR RIGHT COIL SPRING .

NOTE: Front axle removed for purposes of clarity.

Release screws (1 and 2).

Release nuts (3) and loosen wheel arch cover (4) from installation position.

Installation:

Ensure wheel arch cover (4) is correctly seated.

Fig 1: Identifying Nuts And Wheel Arch Cover

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Modify sheet nuts (1)

Installation:

If necessary, replace faulty metal nuts (1).

Fig 2: Identifying Faulty Metal Nuts

Courtesy of BMW OF NORTH AMERICA, INC.
