26 12 011 Replacing grooved ball bearing in center mount of propeller shaft

WARNING: This page is about a different car, the 2010 BMW M3, 2009 BMW M3, and 2008 BMW M3. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

23 1 160

See CLUTCH - SPECIAL TOOLS .

33 3 202
33 3 203

See REAR AXLE - SPECIAL TOOLS .

Necessary preliminary tasks:

Replace propeller shaft center mount

Press grooved ball bearing using special tool 23 1 160 out of center mount (1).

NOTE: Illustration shows E46.

Fig 1: Pressing Grooved Ball Bearing Out Of Centre Mount

Courtesy of BMW OF NORTH AMERICA, INC.

Coat rubber-coated bearing seat of center mount (2) with Circolight.

Using special tools 33 3 202 / 33 3 203 , press new grooved ball bearing (1) into center mount (2).

NOTE: Illustration shows E46.

Fig 2: Pressing Grooved Ball Bearing Into Centre Mount

Courtesy of BMW OF NORTH AMERICA, INC.
