26 12 001 Replacing complete propeller shaft center mount

Special tools required:

• 00 7 500

See MAINTENANCE AND GENERAL INFORMATION - SPECIAL TOOLS .

• 23 1 160

See CLUTCH - SPECIAL TOOLS .

Necessary preliminary tasks:

• Remove propeller shaft  .

Detach gaiter (1) from groove (2).

Mark front propeller shaft (3) and rear propeller shaft (4) in one plane.

Installation:

Make sure gaiter (1) is securely seated in groove (2).

Fig 1: Aligning Front And Rear Propeller Shaft

Courtesy of BMW OF NORTH AMERICA, INC.

Pull propeller shaft apart.

Fig 2: Pulling Propeller Shaft

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

If necessary, insert new clamping ring (1) into front propeller shaft (2).

Fig 3: Inserting Clamping Ring Into Front Propeller Shaft

Courtesy of BMW OF NORTH AMERICA, INC.

Release gaiter (1) with screwdriver from groove (2) and pull off over longitudinal splines.

Installation:

Apply a coating of grease to longitudinal splines on shaft.

Grease, refer to PROPELLER SHAFT - OPERATING FLUIDS .

Push gaiter (1) during installation into groove (2) and make sure it is firmly seated.

Observe markings and force front propeller shaft onto longitudinal splines (markings must be flush).

Fig 4: Pushing Gaiter During Installation Into Groove

Courtesy of BMW OF NORTH AMERICA, INC.

Install special tool 00 7 500  between center mount (1) and universal joint (2).

Fig 5: Identifying Special Tool (00 7 500) Between Centre Mount And Universal Joint

Courtesy of BMW OF NORTH AMERICA, INC.

Using a hydraulic press, force center mount (1) off propeller shaft (2).

Fig 6: Pressing Centre Mount Off Propeller Shaft

Courtesy of BMW OF NORTH AMERICA, INC.

Force new center mount (1) onto propeller shaft. Collar (2) must point in direction of travel towards front propeller shaft. Drive center mount firmly home with special tool 23 1 160  .

Fig 7: Identifying Special Tool (23 1 160 And 33 1 020)

Courtesy of BMW OF NORTH AMERICA, INC.
