63 25 000 Removing and installing/replacing auxiliary brake light (convertible)
WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2013 BMW 328xi, 2013 BMW 328i, 2012 BMW 328xi, 2012 BMW 328i, and 2011 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.
Necessary preliminary tasks:
- Remove panel for rear lid
Disconnect plug connection (1).
Release nuts (3) and remove springs (2) underneath.
Press auxiliary brake light at threaded pins (4) outwards and remove.
Installation:
Make sure auxiliary brake light seal is correctly seated.
Tighten nuts (2) from inside outwards.
Tightening torque: 2.5 Nm +/- 0.5 Nm
