25 11 001 Replacing complete gearshift lever

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2013 BMW 328xi, 2013 BMW 328i, 2012 BMW 328xi, 2012 BMW 328i, and 2011 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove Selector Lever.
Remove Vibration Damper (if fitted).

Detach mount from selector lever.

Installation:

Grease ball joint.

Grease, refer to BMW Service Operating Fluids.

Fig 1: Detaching Mount From Selector Lever

G04726170

Courtesy of BMW OF NORTH AMERICA, INC.

Detach rubber gaiter from selector lever.

Fig 2: Detaching Rubber Gaiter From Selector Lever

G04726171

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Degrease selector lever (1).

Coat rubber bellows on inside of shaped section (2) with Circolight.

Pull rubber gaiter from above over selector lever and align.

Arrow (3) on rubber gaiter must point in direction of travel (A).

Fig 3: Selector Lever, U-Gaiter Shaped Section, Arrow on Gaiter And Installation Direction

G04726172

Courtesy of BMW OF NORTH AMERICA, INC.
