Radiator (View 1 Of 2)
WARNING: This page is about a different variant/trim than selected.
ITEM DESCRIPTION TABLE
| Item | Part Number | Description |
|---|---|---|
| 1 | W527326 | Upper radiator hose clamp |
| 2 | 8B274 | Upper radiator hose |
| 3 | W527351 | Radiator-to-degas bottle hose clamp |
| 4 | 8276 | Radiator-to-degas bottle hose |
| 5 | W527326 | Lower radiator hose clamp |
| 6 | 8B273 | Lower radiator hose |
| 7 | 19710 | A/C condenser-to-radiator pin-type retainer |
